Non-woven Fabric Auto-turret Winding Machine

Description

PNT’s Non-woven Fabric Auto-turret Winding Machine processes thickness of
Min 12 to Max 350g/m2 non-woven fabric.

In particular, by applying the Turret Winding System & Auto Splicing System, workers can minimize the replacement of the fabric, resulting improved productivity.

Machine Specifications



General specification

Web Material

Non-woven fabric

Web Thickness

12~350g/㎡

Web Width

Max. 4,600mm

Roll Width

Max. 4,800mm

Rewinding Type

Auto Turret Winding

Mechanical Speed

Max. 500m/min

Unwind Diameter

Max. 1,500mm

Rewind Diameter

Max. 1,200mm

Winding System

Center Winding System
