Label Slitting Machine

Label Slitting Machine


PNT’s Label Slitter can cut label papers and films with a slitting width of Min 70mm ~ Max 800mm.
Unloading Unit makes easy to unload re-winded web, and Wrapping function enables packaging the product.

Machine Specifications


General specification

Web Material

Paper, Film (Sticker)

Web Thickness

Min.100g/m3 – Max. 300g/m3.

Unwinder Diameter

Max. 1,200mm ~ 800mm

Rewinder Diameter

Max. 800mm ~ 300mm.

Web Width

Max. 1,600mm ~ 470mm.

Roll Width


Mechanical Speed

Max. 400m/min.

Slitting Min width

Min. 70mm ~ 800mm

Slitting type

Shear Cutting system

Winding system

2 Shaft Center winding system.

Label Slitting Machine
